StarTech.com PEXMSATA343 - 3 Port PCIE SATA III Card with MSATA Slot & Hyperduo SSD Tiering

Add 1 internal mSATA slot and 3 internal SATA III (6Gbps) ports to a computer through a PCI Express x2 slot. The PEXMSATA343 3-Port PCI Express 2.0 SATA Card with HyperDuo adds an internal mSATA SSD (Solid State Drive) slot plus three internal SATA III ports to your computer through a PCIe x2 slot adding multiple 6 Gbps internal connections that enable you to improve the overall speed and storage capacity of your computer by connecting high-performance SSDs and hard drives.

Featuring HyperDuo technology the SATA card offers SSD auto-tiering which lets you balance the performance advantages of SSD storage with the cost-effectiveness and large capacity of standard hard drives. By combining SSD and HDD drives into a single volume (up to 3 SSD + 1 HDD) HyperDuo discreetly works in the background to identify and move frequently accessed files to the faster SSD drive(s) for improved data throughput - up to 80% of SSD performance! (Note: The HyperDuo automatic storage tiering feature is compatible with computers that use a BIOS.)

The PCIe SATA controller card offers Port Multiplier (PM) support so multiple SATA drives can be connected over a single cable for a total of 7 drives (Up to 4 drives through PM on one port and a single drive to the remaining 2 ports and mSATA slot). Plus the SATA controller card offers an effective hardware RAID solution with native RAID (0 1) support.

Throughput Benchmark


Drive configuration
Throughput
Drive size

1 x HDD
112.81 MB/s
2 TB

1 x SSD
490.28 MB/S
120 GB

1 x HDD + 1 x SSD HyperDuo (Safe Mode)
489.28 MB/s
2 TB

1 x HDD + 2 x SSD HyperDuo (Safe Mode)
715.13 MB/s
2 TB

Drives Used:
SSD: OCZ Vertex 3 Series 2.5" 120 GB (VTX3-25SAT3-120G)
HDD: Western Digital Caviar Green 3.5" 2 TB (WD20EARS)

Software Used:
IO Meter 256KB Sequential Read queue depth = 10

You can install a SSD directly to the card via a convenient metal latching clip to help relieve the internal space constraints often associated with multiple hard drive configurations. Plus the controller card also includes a low profile/half-height installation bracket for small form factor (SFF) systems.

Backed by a StarTech.com 2-year warranty and free lifetime technical support.
