HPE JW167A - Ap-205H Fips TAA Dual 2X2 11AC Ap

$971.64 $660.98 (You save $310.66)
SKU:
JW167A
Condition:
New
Availability:
Out of Stock

* Prices and ETA can be changed anytime without any prior notice.
** Backorders are subject to cancellation without any prior notice.

The multifunctional and affordable AP-205H access point (AP) combines high-performance wireless mobility with wired Gigabit Ethernet access in a surprisingly compact device.

This compact and cost-effective dual-radio AP easily mounts to a standard data wall-box and uses the existing structured cabling system to provide secure wired and wireless network access in dormitories classrooms hotels medical clinics and multitenant environments.

In addition using a unique mount kit accessory the AP-205H can easily be converted to a desk mounted AP to provide the same benefits for branch offices and teleworkers.

Capable of delivering high-performance Wi-Fi services to multiple rooms the 205H simplifies RF coverage planning and reduces WLAN deployment costs. The AP-205H is built to provide years of trouble-free operation and is backed by Aruba's limited lifetime warranty.

The 205H delivers wireless data rates of up to 867 Mbps to 5-GHz devices with 802.11ac technology leveraging two spatial MIMO streams while simultaneously supporting 2.4-GHz 802.11n clients with data rates of up to 400 Mbps.

The integrated antennas of the 205H are optimized for the deployments with the AP mounted vertically on either a wall or desk. The antenna patterns are slightly directional focusing RF energy to and from the area facing the front of the AP.

Three local Gigabit Ethernet ports are available to securely attach wired devices to your network. One of these ports is also capable of supplying PoE power to the attached device.

The 205H itself receives power from either an AC-to-DC adapter accessory or from the switch it attaches to using PoE via the uplink Gigabit Ethernet port.
General Information
Product NameAp-205H Fips TAA Dual 2X2 11AC Ap
Manufacturer Part NumberJW167A
Product Series205H
Product ModelAP-205H
Product TypeWireless Access Point
Technical Information
Wireless LAN StandardIEEE 802.11ac
Frequency Band5 GHz

2.40 GHz

Total Number of Antennas4
Number of Internal Antennas4
Wireless Transmission Speed867 Mbit/s
MIMO TechnologyYes
Beamforming TechnologyYes
Interfaces/Ports
Ethernet TechnologyGigabit Ethernet
Number of Network (RJ-45) Ports4
PoE (RJ-45) PortNo
PoE PD PortYes
VGANo
HDMINo
USBYes
PowerlineNo
Management PortYes
Physical Characteristics
Form FactorDesktop

Wall Mountable

Height5.9"
Width3.4"
Depth1.6"
Warranty
Limited WarrantyLifetime
Miscellaneous
Environmentally FriendlyYes
Environmental CertificationcTUVus
Other Information
Product Family205H
Stock Details
ManufacturerHPE
Manuf Part#JW167A
AvailabilitySpecial Order
