Cisco Systems
Cisco Systems IE-4010-16S12P - IE4010 16X1G SFP 12X10 100 1000 LAN Base
$5,235.69
- SKU:
- IE-4010-16S12P
- Condition:
- New
- Availability:
- Out of Stock
Cisco® Industrial Ethernet (IE) 4010 Series Switches with 28 Gigabit Ethernet interfaces are high-performance ruggedized Layer2/3 switches with high-density Power-over-Ethernet (PoE) capabilities making them an ideal choice for use as access switches in industrial environments. The 4010 delivers comprehensive Cisco IOS® Software security features and high-availability ring protocols. The switch is ideal for outdoor enclosures or harsh environments while adhering to overall IT network design compliance and performance requirements.
The 4010 has a comprehensive software feature set developed from manufacturing utility and enterprise switching products making it excellent for extended temperature range locations such as smart buildings utility process control intelligent transportation systems (ITS) and city surveillance programs. The 4010 complements the existing Cisco IE 2000 IE 2000U IE 3000 IE 3010 IE 4000 and IE 5000 Series Switching families as well as the Cisco CGS 2520 Switch.
The 4010 supports a GUI-based web user Interface and Express Setup for the switch provides easy out-of-box configuration to deliver advanced security data video and voice services over industrial networks.
The 4010 has a comprehensive software feature set developed from manufacturing utility and enterprise switching products making it excellent for extended temperature range locations such as smart buildings utility process control intelligent transportation systems (ITS) and city surveillance programs. The 4010 complements the existing Cisco IE 2000 IE 2000U IE 3000 IE 3010 IE 4000 and IE 5000 Series Switching families as well as the Cisco CGS 2520 Switch.
The 4010 supports a GUI-based web user Interface and Express Setup for the switch provides easy out-of-box configuration to deliver advanced security data video and voice services over industrial networks.
General Information | |
Product Name | IE4010 16X1G SFP 12X10 100 1000 LAN Base |
Product Series | 4010 |
Product Model | IE-4010-16S12P |
Product Type | Ethernet Switch |
Interfaces/Ports | |
Total Number of Network Ports | 12 |
Uplink Port | Yes |
Modular | Yes |
Stack Port | No |
Port / Expansion Slot Details | 12 x Gigabit Ethernet Network 12 x Gigabit Ethernet Expansion Slot 4 x Gigabit Ethernet Uplink |
I/O Expansions | |
Number of Total Expansion Slots | 16 |
Expansion Slot Type | SFP |
Shared SFP Slot | No |
Number of SFP Slots | 16 |
Media & Performance | |
Media Type Supported | Optical Fiber Twisted Pair |
Ethernet Technology | Gigabit Ethernet |
Network Technology | 1000Base-X 10/100/1000Base-T |
Network & Communication | |
Layer Supported | 3 |
Power Description | |
Power Source | Power Supply |
Redundant Power Supply Supported | Yes |
Management & Protocols | |
Manageable | Yes |
Physical Characteristics | |
Compatible Rack Unit | 1U |
Form Factor | Rack-mountable |
Height | 1.8" |
Width | 17.5" |
Depth | 14" |
Warranty | |
Limited Warranty | 5 Year |
Miscellaneous | |
Environmentally Friendly | Yes |
Other Information | |
Product Family | 4010 |
Stock Details | |
Manufacturer | Cisco Systems |
Manuf Part# | IE-4010-16S12P |
Price | $4230.85 |
Availability | Special Order |
